Leader Wood
Leader branded H20 wood beams
Share
Leader H20 Beams provide lightweight, engineered wood solutions for structural and formwork needs, ensuring stability and reduced material waste
Leader H20 Timber Beam is a professional structural timber beam specially engineered for construction formwork and scaffolding systems.
Constructed with two solid wood flanges and a high-pressure compressed 3-layer/multi-layer plywood core web, our standard Leader H20 beam features dimensions: 200mm height, 80mm overall width and 40mm flange thickness. Custom lengths ranging from 1.8m to 5.9m are fully available to meet diverse on-site construction demands.
Manufactured with premium raw materials, the beam flanges adopt durable European spruce, while the inner core web is laminated with high-strength poplar or eucalyptus veneers. Equipped with neatly chamfered ends and reinforced plastic or steel end caps, Leader H20 beams are effectively protected against collision, abrasion and construction damage.
Thanks to its sophisticated structural design and strict production craftsmanship, Leader branded H20 wood beams deliver outstanding advantages including superior load-bearing capacity, ultra-long service life, lightweight property and excellent dimensional stability even after frequent repeated usage.
As a reliable Chinese professional manufacturer dedicated to premium H20 timber beams, Leader Wood guarantees stable quality and competitive factory prices. Feel free to contact us anytime to get your favorable quotation and bulk order solutions.
Products Show
Every Process Perfected, Every Industry Standard Redefined.Please swipe left and right screen.
Product Parameter
Product Name:
H20 beams-Durable Formwork Beams for Construction Projects
Brand Name:
Leader
Length:
2.45/2.65/2.9/3.3/3.9/4.5/4.9/5.9m; Customized According To Customers
Beam Height:
200mm(+-0.2mm)
Flange Width:
80mm(-1.2mm-0.8mm)
Flange Height:
40mm(+-0.6mm)
Web thickness:
27mm/30mm(+-1mm)
The Material of Flange:
Graded timber or Structural laminated lumber
Web:
plywood/3 layers-Plywood
Flange wood species:
softwood
Service Class:
3(exterior conditions)
Adhesive:
Type I per EN301
Moisture Content:
12+-2% at time of dispatching
Weight:
Approx 5.0kg/m
Standard packaging:
50/100/105pcs per package
Packaging:
Standard export packaging, or according to customer requirements for packaging
Application:
Construction,formwork,roof joists,Floor Joist,I-Joist Wall,Wall formworks,Ceiling Formworks,Working platforms,Scaffolding
Payment Terms:
T/T,30% deposit, 70% balance before shipment or container loading;L/C option available
Delivery Time:
7-14 days after receiving deposit
